1、 Introduction
This series of products adopts power electronic transformation and intelligent control technology, mainly for the ground power supply of aircraft and airborne equipment, and high-performance power supply designed for the test of military electronic and electrical equipment.
2、 Applicable occasions
It is mainly used for aircraft and airborne equipment, radar, navigation and other occasions with 400Hz power supply requirements. It is the replacement product of traditional generator set frequency conversion power supply. Users are customer groups such as aviation research institute, military factory, army, civil aviation, etc., which are used in laboratories, electrical workshops, measurement and testing rooms, aircraft hangars, aprons and other occasions.
3、 Executive standard
Power supply characteristics of gjb181a-2003 aircraft
GJB572A-2006 aircraft external power supply characteristics and general requirements
MH / t6018 ground static transformer power supply
Power supply characteristics of mil-std-704e aircraft
1. Three phase independent design, each phase can be independently adjustable;
2. Cable voltage drop automatic compensation function;
3. High brightness liquid crystal display, optimized man-machine interface, simple operation;
4. The output intercepting function can meet the requirements of shock load starting;
5. High frequency switching technology, multi loop control, high quality output waveform, fast response time, good dynamic characteristics;
6. Power on self check function ensures stable and reliable operation process;
7. Superior overload capacity design can meet the working requirements of different loads;
8. Optimize the air duct design, improve the cooling capacity of the power supply, reduce the heat loss, and extend the product life.
規 格
|
ASK系列
|
|
功率等級
|
1-3kVA
|
6-30kVA
|
30-90kVA
|
90-150kVA
|
150—210kVA
|
|
輸入
技術
指標
|
相數
|
單相+PE
|
三相三線+PE
|
|
電壓
|
220V±10％
|
380V±15％
|
|
頻率
|
50Hz±5％
|
|
輸 出
技術
指標
|
電壓
|
115V/200V±20％
|
|
電壓調節分辨率
|
0.1V
|
|
穩壓精度
|
≤±1％FS
|
|
頻率
|
400Hz±20％
|
|
頻率調節分辨率
|
0.1Hz
|
|
頻率精度
|
≤±0.01％FS
|
|
總諧波失真
|
THD≤2％（阻性負載測試）
|
|
過載能力
|
125％?60分鐘，150％ 10分鐘，200％ 1分鐘保護
|
|
相位差
|
120°±2°(1/3不平衡)，120°±4°(完全不平衡)
|
|
動態特性
|
超調＜15％，動態響應時間＜1mS，恢復時間滿足GJB181要求
|
|
保護功能
|
輸入過、欠壓，輸出過壓、過載、短路、截流，缺相，內部過熱
|
|
操作
顯示
|
顯示方式
|
LCD面板，觸摸按鍵操作
|
|
顯示內容
|
顯示電壓/電流/頻率/運行狀態/故障信息/控制模式（本控/遠控）
|
|
顯示精度
|
電壓±1％FS，電流±2％FS，頻率±0.1％FS
|
|
綜 合
特性
|
抗沖擊特性
|
抗電網是瞬間波動能力強，能有效的擬制來自電網的浪涌、下陷、尖峰等各種干擾
|
|
效率
|
≥80%
|
≥85%
|
≥90%
|
|
噪聲
|
≤55dB
|
≤60dB
|
≤65dB
|
|
進出線方式
|
背部進出線
|
|
環境
|
溫度等級
|
民用級：-5℃～40℃、工業級：-25℃～50℃、級：-40℃～55℃
|
|
冷卻裝置
|
強制風扇冷卻
|
|
工作、存儲濕度
|
30%RH-90%RH(無凝露)/ 10%RH-95%RH(無凝露)
|
|
控 制
方式
|
本地控制
|
LCD面板，觸摸按鍵操作
|
|
遠程控制
|
RS-232、RS-485、GPIB(可選其一)
|
|
可靠性
|
MTBF
|
1.0×105h
|
|
MTTR
|
0.5h
|
|
安全性
|
絕緣電抗
|
500Vdc、20MΩ以上
|
|
耐壓絕緣
|
1800Vdc/5mA/1min
|
|
尺寸
|
(寬×高×深)mm
|
（1）
|
（2）
|
（3）
|
（4）
|
（5）
|
|
重量
|
參考值（KG）
|
35
|
190
|
370
|
650
|
1500
|
